Product Summary
The S7815D is a three-terminal positive regulator providing over 1A output current with internal current limiting, thermal shutdown and safe area protection. The S7815D is useful in a wide range of applications. Although they are just fixed voltage regulators, the S7815D can be used with external components to obtain adjustable voltages and currents.
Parametrics
S7815D absolute maximum ratings: (1)Operating Input voltage VIN: 35 (ALL Others)V; (2)Power Dissipation (without Heatsink)PD: 1.3 W; (3)Operating Junction Temperature TJ: -30 ~ 125 ℃; (4)Storage Temperature Tstg: -55 ~ 150 ℃; (5)Peak Output Current IPK Tj =25℃: 2.2A.
Features
S7815D features: (1)Internal Short Circuit Current Limiting; (2)Maximum Output Current (1A Max.); (3)Thermal Overload Protection; (4)Output Transistor Safe Area Protection.
Diagrams
